Filter Regulator Lubricator - Air Filter Regulator Lubricator | FRL6

Air Filter Regulator Lubricator | FRL



Air Filter Regulator Lubricator includes Pneumatic Air Filter | AF, Pneumatic Air Regulator | AR, Pneumatic Air Lubricator | AL, Pneumatic Air Regulator can stabilize the air source and keep the air source in a constant state, and reduce damage to the valve or actuator and other hardware due to sudden changes in air supply pressure. The Pneumatic Air Filter is used to clean the air and filter the water in the compressed air to avoid the water entering the device with the air. The Pneumatic Air Lubricator lubricates the moving parts of the body and lubricates parts that are inconvenient to lubricate, greatly extending the life of the body.
  • Air Filter Regulator Lubricator AC (Overflow Type)

    AC Series Air Filter Regulator Lubricator is made up of three parts: water-separating gas filter, pressure reducing valve and Lubricator. FRL has the characteristics of small size, light weight, good performance, convenient use, beautiful appearance and so on.

    Working Medium: Compressed Air
    Range of pressure regulation: 0.05~0.85MPa
    Ambient temperature: 5~60℃
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Structure: AC1000: Overflow Type
    Learn more
  • Air Filter Regulator Lubricator AC

    AC Series Three Units Air Combination is made up of three parts: water-separating gas filter, pressure reducing valve and Lubricator. The AC Air Combination connected by three parts without pipes are called FRL.

    Working Medium: Compressed Air
    Proof Pressure: 1.5MPa
    Ambient temperature: 5~60℃
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Range of pressure regulation: AC1000: 0.05-0.7MPa, AC2000-5000: 0.05-0.85MPa
    Learn more
  • Air Filter Regulator Lubricator AB

    From left to right, FRL Combination AB Series is Filter, Regulator and Lubricator. The pressure regulating range of the Regulator is 0~1.0MPA, the pressure is increased by clockwise adjustment , and the pressure is reduced by counterclockwise adjustment.

    Working Medium: Compressed Air
    Proof Pressure: 1.5MPa
    Ambient temperature: 5~60℃
    Range of pressure regulation: 0.5~0.85MPa
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Learn more
  • Air Filter Regulator Lubricator FRL700A

    FRL700A Air Combination remove water and particle effectively. Miniature 3 Units Air Combination has compact size with effective air service. 40µm and 5µm filter element are easily interchangeable and replaceable. Accurate and easy pressure setting.

    Working Medium: Compressed Air
    Proof Pressure: 1.0MPa
    Ambient temperature: -10~60℃
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Range of pressure regulation: 0.05~0.8MPa
    Learn more
  • Air Filter Regulator Lubricator GC

    GC Air Combination has fast and reliable fixed connection, easy to install and use. Pressure regulation is stable and repeatability is high. Efficient water and solid particle removal function; There are three forms of drainage, such as manual, differential pressure and automatic drainage.

    Working Medium: Compressed Air
    Proof Pressure: 1.5MPa
    Ambient temperature: -20~70℃
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Range of pressure regulation: 0.05~0.85MPa
    Learn more
  • Air Filter Regulator Lubricator UFRL

    UFRL 3 Units Combination has 360˚ Omni-directional Visual Lubricator Observation Window, Air Combination remove water and particle very effectively. Accurate and easy pressure setting. Lubricator can be replenished without stopping air supply.

    Working Medium: Compressed Air
    Proof Pressure: 1.5MPa
    Ambient temperature: -10~60℃
    Filtration aperture: 40μm(routine) or 5μm(customized)
    Range of pressure regulation: 0.05~0.9MPa
    Learn more
